| CPU | Rockchip RK3568, 4 cores A55, main frequency 2.0GHz Rockchip | RK3288, 4 cores A17, main frequency 1.8GHz Allwinner A133P, 4 cores | A53, main frequency 1.8GHZ |
| Memory + Storage | 2GB+16GB，4GB+32GB，8GB+64GB | 2GB+16GB，4GB+32GB | 1GB+8GB，2GB+16GB，4GB+32GB |
| Android System | Android 11/12/13 | Android 7.1/5.1/6.0/8.1 | Android 10 |
| Linux System | Ubuntu 20.04/Linux QT/Debian11 | Ubuntu 18.04/Linux QT/Debian 9 | Ubuntu 18.04/Linux QT |
| HDMI | HDMI2.0 interface, up to 4K resolution, supports dual-screen display | Not supported | |
| 백라이트 밝기 | 500 CD/m2 (optional 1000cd/m2) | ||
| 시야각 | 전체보기 | ||
| LCD screen type | IPS | ||
| 터치 방식 | 5-포인트 용량 성 접촉 (optional non-touch) | ||
| Ethernet | 10/100/1000M adaptive Ethernet | 10/100M adaptive Ethernet | |
| WiFi/Bluetooth | Standard single-band WiFi6 (optional dual-band WiFi6), Bluetooth 5.2 | ||
| 4G/5G | Optional 4G/5G module, onboard Micro-SIM card slot | ||
| GPS | Optional 4G module with GPS function | ||
| USB | USB 3.0*1,USB 2.0*3,USB 3.0 OTG*1 | USB 2.0*4，USB OTG*1 | |
| TF card | Self-pop-up TF card socket, supports up to 256GB | ||
| Serial port | 2-way TTL, 2-way RS232, 2-way RS485 (optional 6-way TTL or 4-way RS232) | ||
| GPIO | 4-way GPIO signal | ||
| CAN | COM6 can be selected as CAN port | Not supported | |
| Access control | Not supported | COM6 can be selected as access control interface | |
| Audio | 1-way 4-band headset integrated 3.5mm socket, 1-way 8 ohm 6W dual-way audio speaker interface | ||
| User buttons | Reset button, return button, 용량 + button, 용량 – button, burn button | ||
| 주도의 | Power light, operation indicator light, WiFi indicator light, 4G/5G network indicator light | ||
| 전원 공급 장치 | DC-12V±5%/DC-24V±5% power supply standby power consumption: 0.42여 | ||
| 치수 | Opening size 184.1*115.9mm Overall size 195.5*127.5*28.5mm Outer packaging size 233*160*52mm | ||
| 무게 | Nude weight 0.7015kg Package weight 0.8215kg | ||
| Rated power | 4.5여 | ||
| 작동 전압 | 12~ 24V, 전형적인 값 12V | ||
| 온도 | Working temperature -10°C~60°C Storage temperature -20°C~70°C | ||
| 작동 습도 | 0%~95% (no condensation) | ||
Excellent touch performance
5-point capacitive touch screen, strong anti-interference abilitysupports glove touch and wet hand touch.
7-inch Android industrial control all-in-one computers (equipped with glove-friendly touchscreens, embedded industrial control capacitive screens, and high-definition displays) are widely used in industrial and commercial scenarios requiring human-computer interaction due to their durability, high touch sensitivity, and portability. Typical application scenarios and product categories are as follows:
1. Industrial Automation and Manufacturing
Equipment Control Terminals: Used for PLC control, production line monitoring, and robotic arm operation interfaces.
Quality Inspection Tools: Rapidly input inspection data on the production line, supporting glove operation and suitable for dust-free environments.
Warehousing and Logistics: Terminals for AGV dispatching and warehouse management systems (WMS), resistant to oil, dirt, and dust.
2. Medical and Laboratory
Medical Device Interaction: Embedded installation in diagnostic instruments and monitoring equipment, supporting gloved operation by medical personnel.
Laboratory Recorders: Corrosion-resistant screens for chemical or biological laboratories, compatible with protective gloves.
3. Outdoor and Harsh Environments
In-Vehicle Systems: Onboard computers for construction vehicles and forklifts, with shock and dust resistance.
Agricultural Machinery: Intelligent control panels for tractors and harvesters, 고온 환경 및 저온 환경에 적합합니다.
